Product Details
Place of Origin: Henan, China
Brand Name: Zhenglan Cable
Certification: 3C，ISO 9001:2015，ISO 14001:2005
Model Number: JKTRYJ-10KV
Payment & Shipping Terms
Minimum Order Quantity: 100 meters
Packaging Details: Wooden case, wooden-steel case, coil or plastic drumor customized
Delivery Time: 15-30 days
Payment Terms: L/C, T/T,
Supply Ability: 100Km/Month
Insulation Material: |
XLPE |
Voltage: |
Low Voltage/Medium Voltage |
Usage: |
Overhead Fixed Layout And Wire Conducting |
Type: |
Low Voltage/Medium Voltage |
Standards: |
IEC60502 |
Conductor Material: |
Copper, Aluminum,aluminum Alloy |
Insulation Material: |
XLPE |
Voltage: |
Low Voltage/Medium Voltage |
Usage: |
Overhead Fixed Layout And Wire Conducting |
Type: |
Low Voltage/Medium Voltage |
Standards: |
IEC60502 |
Conductor Material: |
Copper, Aluminum,aluminum Alloy |
10kV JKTRYJ Copper Overhead Insulated Cable , Flexible 70mm2 MV Lv Abc Cable
Place of Origin: Henan,China (Mainland)
Brand Name: ZHENGLAN
Insulation Material: XLPE
Type: Low Voltage/Medium Voltage
Application: Overhead or Power station
Conductor Material: copper, aluminum,aluminum alloy
Standards: IEC60502
Packaging Details: Wooden case, wooden-steel case, coil or plastic drumor customized
Overhead Insulated Cable Application:
Overhead insulated cables have the advantages of simple structure, safety and reliability, excellent physical and electrical mechanical properties, and resistance to environmental ultraviolet rays. Due to the use of special insulated cable materials for weather resistance, the long-term allowable operating temperature of the cable is as high as 70°C or 90°C. Excellent electrical insulation performance, volume resistivity of 1.0×10^12Ω.m or more; in laying, the use of overhead insulated cables can reduce the laying of gaps, save line corridors, reduce voltage drop; in use, can reduce the power supply accident Occurs to ensure personal safety.
| Type | No. of wire/Diameter | Conductor Diameter (mm) | Conductor Screen (mm) | Insulation Thickness (mm) | Approx. Diameter (mm) | Approx. Weight (kg/km) |
|---|---|---|---|---|---|---|
| 1×10 | 7/1.35 | 4.0 | 0.6 | 3.4 | 12.2 | 185.1 |
| 1×16 | 7/1.66 | 5.0 | 0.6 | 3.4 | 13.2 | 249.7 |
| 1×25 | 7/2.16 | 6.0 | 0.6 | 3.4 | 14.2 | 340.4 |
| 1×35 | 7/2.52 | 7.0 | 0.6 | 3.4 | 15.2 | 439.8 |
| 1×50 | 10/2.52 | 8.4 | 0.6 | 3.4 | 16.6 | 578.8 |
| 1×70 | 14/2.52 | 10.0 | 0.6 | 3.4 | 18.2 | 769.1 |
| 1×95 | 19/2.52 | 11.6 | 0.7 | 3.4 | 20.1 | 1028.6 |
| 1×120 | 25/2.52 | 13.0 | 0.7 | 3.4 | 21.5 | 1264.3 |
| 1×150 | 30/2.52 | 14.6 | 0.7 | 3.4 | 23.1 | 1546.1 |
| 1×185 | 37/2.52 | 16.2 | 0.7 | 3.4 | 24.7 | 1871.5 |
| 1×240 | 49/2.52 | 18.5 | 0.7 | 3.4 | 27.0 | 2380.1 |
