0.6/1KV Armoured 1.5~1000mm2 2 Cores LV Steel LV Wire Cable(Power Cable) （CU/PVC/XLPE/STA/NYBY/N2XBY)

0.6/1KV Armoured 1.5~1000mm2 2 Cores LV Steel LV Wire Cable(Power Cable) (CU/PVC/XLPE/STA/NYBY/N2XBY)

1.Quick Details
Place of Origin: Henan, China (Mainland)
Brand Name: ZHENGLAN
Insulation Material: XLPE
Type: Low Voltage
Application: Construction
Conductor Material: Copper/Aluminum
Jacket: PVC
Sizes: 1.5~1000mm2
Insulation color: Red, yellow, green all according to clients demand
Number of cores: 1-5cores
Rated voltage: 0.6/1KV
Packaging Details: fully wooden drum, steel wooden drum, fully steel drum or customized

Construction
1.Conductor : Compact stranded copper conductor , Cl 2 as per IEC 60228
2.Insulation : XLPE ( cross-linked polyethylene ) rated at 90℃
3.Inner covering : PVC
4.Armoring : Aluminum wire
5.Sheath : PVC or fr-pvc type ST2 to IEC 60502 , black

Code Destination
YJ : XLPE insulation
V : PVC sheath
72 : Aluminum wire armoring
ZR : Flame resistant

Applications
Apply to shafts , water and soil , able to bear the larger positive pressure

Standards
International : IEC 60502, EC60228, EC 60332
China GB / T 12706 .1-2008
Other standards such as BS , DIN and ICEA upon request

Technical data

Rated voltage : 0.6 / 1 kv

Maximum Conductor Temperature : under normal ( 90℃) , emergency ( 130℃) or short circuit no more than 5 s ( 250℃) conditions.
Min. Ambient Temp . -15℃, Installation Temp . 0℃
Min. Bending Radius : 15 x cable O.D. for single core

Why Choose Zhenglan Cable:

• OEM/ODM services provided
• Products comply with GB, IEC, BS, ASTM, DIN, VDE and JIS standards; Customer standard requirments Accepted
• Certified to ISO 9001:2015, ISO 14001:2015 and OHSAS 18001:2007
• Registered capital of $30 million and factory covers an area of 60,000㎡
• Advanced test equipment and procedures, 100% inspection before factory
• Enough stocks and the higest efficient shipping time guarranteed
• Professional pre-sales and after-sales services provided


  Model	Description
  YJV(YJLV)	Copper(Aluminum) core XLPE insulated PVC sheathed power cable
  YJV22(YJLV22)	Copper(Aluminum) core XLPE insulated steel tape armoured and PVC sheathed power cable
  YJV32(YJLV32)	Copper(Aluminum) core XLPE insulated steel wire armoured and PVC sheathed power cable
  ZR-YJV(ZR-YJLV)	Copper(Aluminum) core XLPE insulated flame retardant PVC sheathed power cable
  ZR-YJV22(ZR-YJLV22)	Copper(Aluminum) core XLPE insulated steel tape armoured and flame retardant PVC sheathed power cable
  ZR-YJV32(ZR-YJLV32)	Copper(Aluminum) core XLPE insulated steel wire armoured and flame retardant PVC sheathed power cable

•
•
•
•
