0.6/1kV XLPE Insulated Cables / PVC Sheathed Power Cable(N2XY/NA2XY) (CU/XLPE/LSZH/DSTA)

0.6/1kV XLPE Insulated Cables /  PVC Sheathed Power Cable(N2XY/NA2XY) (CU/XLPE/LSZH/DSTA)
0.6/1kV XLPE Insulated Cables /  PVC Sheathed Power Cable(N2XY/NA2XY) (CU/XLPE/LSZH/DSTA)
0.6/1kV XLPE Insulated Cables /  PVC Sheathed Power Cable(N2XY/NA2XY) (CU/XLPE/LSZH/DSTA) 0.6/1kV XLPE Insulated Cables /  PVC Sheathed Power Cable(N2XY/NA2XY) (CU/XLPE/LSZH/DSTA) 0.6/1kV XLPE Insulated Cables /  PVC Sheathed Power Cable(N2XY/NA2XY) (CU/XLPE/LSZH/DSTA)

Large Image :  0.6/1kV XLPE Insulated Cables / PVC Sheathed Power Cable(N2XY/NA2XY) (CU/XLPE/LSZH/DSTA)

Product Details:
Place of Origin: China
Brand Name: Zhenglan cable
Certification: 3C; ISO 9001:2015, ISO 14001:2005, OHSAS 18001:2007
Model Number: 0.6/1kV Oxygen free Copper Conductor, XLPE Insulated,
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: Wooden drum, wood and steel drum,as customer's request
Delivery Time: 7-10 Working Days
Payment Terms: L/C, T/T, , Western Union

0.6/1kV XLPE Insulated Cables / PVC Sheathed Power Cable(N2XY/NA2XY) (CU/XLPE/LSZH/DSTA)

Description
Material: CU Application: Power Station
Insulation: XLPE Sheath: PVC
Armour: SWA/STA Standard: IEC60502, IEC, BS, UL, JIS
High Light:

xlpe insulated pvc sheathed cable

,

xlpe power cable

,

0.6KV XLPE Insulated Cables

High quality 0.6/1kV Oxygen free Copper(Al) Conductor, XLPE Insulated, PVC Sheathed Power Cable(N2XY/NA2XY)

Application
Laying in the room, tunnels, cable trenches and pipes, can also be buried in loose soil, the cable can not withstand mechanical external force. Single-core cable is not allowed to lay in the magnetic pipe. Used for power station, industry, switch gear and urban power supply network.

Standards
Basic design to IEC 60502-1, IEC 60228
China: GB/T 12706.2-2008
Other standards such as BS7870,DIN and ICEA upon request

Cable Construction

ConductorThe conductors shall be either of Class 1 or Class 2 of plain or metal-coated annealed copper or of plain aluminium, or of Class 5 of plain or metal-coated copper in accordance with IEC 60228.
Conductor ShapeCircular Stranded or Compacted Circular Stranded
Appearance ShapeCircular
InsulationXLPE Insulation material and thickness shall be as per IEC 60502-1, rated for 90°C continuous operation.
Sheath Materialextruded PVC Type ST1/ST2 as per IEC 60502-1. Can be supplied with special flame retardant PVC outer sheath to comply with the flame test requirements of IEC 60332-3-22, IEC 60332-3-23 and IEC 60332-3-24, Halogen Free material comply to IEC60754-1/2 and IEC 60684-2.


Characteristics
XLPE insulated power cable features mechanical strength, aging, environmental stress and chemical resistance, available for working under high temperature condition for long.

Electrical Properties/Working Conditions

Rated Voltage Uo/U (Um)600/1000V, BS5467
Installation TemperatureMinimum: 0°C,Maximum: 60°C
Installation TypeOutdoor Direct burial
Operating TemperatureMaximum: 90°C.
Short-circuit Maximum Conductor Temperature:250°C.
Min. Bending Radius15 x cable O.D for multi-core non-armoured cables


Packing Details
1. standard seaworthy drum (wooden drum,wooden steel drum, steel drum) are available;
2. drum size can be customized or meeting container the Max.load size;
3. drum overall diameter can be from 1 meter to 2.5 meters;
4. under customer requirement with certain length packed in rolls wrapped in plastic tape or Nylon plastic tape.

Construction Parameters

IEC 60502-1

Nominal Cross SectionDiameter of Conductor (Approx.)Nominal Insulation ThicknessNominal Sheath ThicknessOverall Diameter (Approx.)
mm^2mmmmmmmm
3x1.51.40.71.89.6
3x2.51.80.71.810.5
3x42.30.71.811.6
3x62.80.71.812.6
3x103.60.71.814.4
3x164.50.71.816.3
3x255.60.91.819.5
3x356.70.91.821.9
3x50811.825.1
3x709.41.11.928.7
3x95111.1232.4
3x12012.41.22.136.1
3x15013.81.42.340.3
3x18515.31.62.444.6
3x24017.51.72.650.2
3x30019.51.82.755.2
3x40022.62363.3



Products show
0.6/1kV XLPE Insulated Cables /  PVC Sheathed Power Cable(N2XY/NA2XY) (CU/XLPE/LSZH/DSTA) 0
0.6/1kV XLPE Insulated Cables /  PVC Sheathed Power Cable(N2XY/NA2XY) (CU/XLPE/LSZH/DSTA) 10.6/1kV XLPE Insulated Cables /  PVC Sheathed Power Cable(N2XY/NA2XY) (CU/XLPE/LSZH/DSTA) 2
