Product Details:
Place of Origin: Henan, China
Brand Name: Zhenglan Cable
Certification: 3C,ISO 9001:2015,ISO 14001:2005
Model Number: YJV22-0.6/1KV
Payment & Shipping Terms:
Minimum Order Quantity: 200 meters
Packaging Details: Fully wooden drum, steel wooden drum, fully steel drum or customized
Delivery Time: 15-30 days
Payment Terms: L/C, T/T,

Armoured 4core 150mm2 XLPE insulation PVC jacket power cable/flame-retardant cable(CU/PVC/XLPE/LSZH/STA/NYBY/N2XBY)

Description
Jacket: PVC Insulation Material: XLPE
Size: 1.5~1000mm2 Type: Low Voltage
Application: Construction Number Of Cores: 4
Rated Voltage: 0.6kv/1kv Conductor Material: Copper/AL
High Light:

low voltage electrical cable

,

low voltage underground cable

1.Quick Details
Place of Origin: Henan, China (Mainland)
Brand Name: ZHENGLAN
Insulation Material: XLPE
Type: Low Voltage
Application: Construction
Conductor Material: Copper
Jacket: PVC
Nominal Section:4*1.5~4*400mm²
Insulation color: Red, yellow, green all according to clients demand
Number of cores: 4cores
Rated voltage: 0.6kv/1kv
Packaging Details: fully wooden drum, steel wooden drum, fully steel drum or customized

2.Application
PVC Insulated and Sheathed Power Cable are suitable to be laid for distribution line with A.C.50HZ and rated voltage up to 1kV. With the characteristics of stable capability, advanced technology, broad material resources, low price, good flexible and easy to lay and maintain.

3.Product Standard
The cable is manufactured according to the standard of GB/T 12706-2008, also can according to customer needs.

4.Technology Property
1)The long-term permissible operation temperature of the conductor shall not be higher than 70℃.
2) Conductor maximum short circuit((less than 5 second) temperature shall not be higher than 160℃.
3) The cable is not limited by drop in level when being laid, and the environment temperature shall not be lower than 0℃.
4) Perfect chemical stability, resistant against acids, alkalis, grease and organic solvents, and flame retardance.
5) Light weight, perfect bending properties, installed and maintained easily and conveniently.

Why Choose Zhenglan Cable:

  • OEM/ODM services provided
  • Products comply with GB, IEC, BS, ASTM, DIN, VDE and JIS standards; Customer standard requirments Accepted
  • Certified to ISO 9001:2015, ISO 14001:2015 and OHSAS 18001:2007
  • Registered capital of $30 million and factory covers an area of 60,000㎡
  • Advanced test equipment and procedures, 100% inspection before factory
  • Enough stocks and the higest efficient shipping time guarranteed
  • Professional pre-sales and after-sales services provided
    Model Description
    YJV(YJLV) Copper(Aluminum) core XLPE insulated PVC sheathed power cable
    YJV22(YJLV22) Copper(Aluminum) core XLPE insulated steel tape armoured and PVC sheathed power cable
    YJV32(YJLV32) Copper(Aluminum) core XLPE insulated steel wire armoured and PVC sheathed power cable
    ZR-YJV(ZR-YJLV) Copper(Aluminum) core XLPE insulated flame retardant PVC sheathed power cable
    ZR-YJV22(ZR-YJLV22) Copper(Aluminum) core XLPE insulated steel tape armoured and flame retardant PVC sheathed power cable
    ZR-YJV32(ZR-YJLV32) Copper(Aluminum) core XLPE insulated steel wire armoured and flame retardant PVC sheathed power cable
