450/750V BV 300mm2 Single Core Solid Copper PVC Insulated Electrical Wire IEC 60228

Name: 450/750V BV 300mm2 Single Core Solid Copper PVC Insulated Electrical Wire IEC 60228
Brand: Zhenglan Cable Technology Co., Ltd
SKU: 450/750v BV CU/PVC 300mm2
Price: 49.50 USD
Availability: InStock

Product Details

Place of Origin: Henan, China

Brand Name: ZhengLan

Certification: ISO9001,CCC, CE, Etc

Model Number: 450/750v BV CU/PVC 300mm2

Payment & Shipping Terms

Minimum Order Quantity: 500 meters

Price: Negotiable

Packaging Details: Fully wooden drum, steel wooden drum, fully steel drum or customized

Delivery Time: 7-10 Working Days

Payment Terms: L/C,T/T,Western Union

Supply Ability: 80000m/day

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                            450/750V BV single core electrical wire, 300mm2 solid copper PVC insulated cable, IEC 60228 compliant electrical wire


Insulation Material:	PVC	Size:	300mm2
Type:	Low Voltage	Rated Voltage:	450/750v
Conductor Material:	Cu

Insulation Material:	PVC
Size:	300mm2
Type:	Low Voltage
Rated Voltage:	450/750v
Conductor Material:	Cu

450/750V BV 300mm2 Single Core Solid Copper PVC Insulated Electrical Wire IEC 60228

Applications

Ideal for fixed laying in indoor conduits, cable trays and distribution rooms. Widely applied for main power wiring of industrial equipment, commercial buildings, residential projects and low-voltage complete electrical devices. Suitable for 450/750V AC power distribution systems for heavy-load power transmission.

Product Features

Built with high-purity solid copper conductor for stable large-current transmission and low power loss. Uniform PVC insulation provides reliable electric insulation, moisture resistance and mechanical protection. Simple structure, easy stripping and terminal connection. Excellent ageing resistance and safety performance for long-term stationary installation.

Item	Specification
Model	BV 450/750V 300mm²
Rated Voltage	450/750V AC
Conductor Material	High-purity Solid Copper
Insulation Material	PVC
Nominal Cross Section	300mm²
Max. Long-term Working Temperature	70℃
Minimum Bending Radius	8× Wire Outer Diameter
Reference Outer Diameter	22.5mm
Reference Weight	2780kg/km
Installation Type	Fixed Indoor Wiring Only

450/750V BV 300mm2 Single Core Solid Copper PVC Insulated Electrical Wire IEC 60228

Why Choose Zhenglan Cable:

OEM/ODM services provided
Products comply with GB, IEC, BS, ASTM, DIN, VDE and JIS standards; Customer standard requirments Accepted
Certified to ISO 9001:2015, ISO 14001:2015 and OHSAS 18001:2007
Registered capital of $30 million and factory covers an area of 60,000㎡
Advanced test equipment and procedures, 100% inspection before factory
Enough stocks and the higest efficient shipping time guarranteed
Professional pre-sales and after-sales services provided
