Home > Products > Fire Resistant Cables > XLPE Insulation Fire Resistant Cables/ Low Voltage Cable Standard for ISO 9001 / CCC Certificate

XLPE Insulation Fire Resistant Cables/ Low Voltage Cable Standard for ISO 9001 / CCC Certificate

Product Details

Place of Origin: Henan, China

Brand Name: Zhenglan Cable

Certification: ISO9001,CCC, CE, Etc

Model Number: ZR-YJV22-8.7/10KV-3*150MM2-#8257

Payment & Shipping Terms

Minimum Order Quantity: 200 meters

Price: 45USD/m

Packaging Details: Fully wooden drum, steel wooden drum, fully steel drum or customized

Delivery Time: 15-30 days

Payment Terms: L/C, T/T,

Supply Ability: 10000m/day

Get Best Price
Highlight:

heat resistant flexible cable

,

fire retardant low smoke cable

Jacket:
PVC Or Low Smoke Halogen Free Polyolefin Jacket
Insulation Material:
XLPE
Size:
1.5~1000mm2
Type:
Low Voltage
Rated Voltage:
0.6kv/1kv
Conductor Material:
1.5mm2 - 2.5mm2 : Class 1 Solid Conductor According To BS EN 60228 4mm2 : Class 2 Stranded Conductor According To BS EN 60228
Jacket:
PVC Or Low Smoke Halogen Free Polyolefin Jacket
Insulation Material:
XLPE
Size:
1.5~1000mm2
Type:
Low Voltage
Rated Voltage:
0.6kv/1kv
Conductor Material:
1.5mm2 - 2.5mm2 : Class 1 Solid Conductor According To BS EN 60228 4mm2 : Class 2 Stranded Conductor According To BS EN 60228
XLPE Insulation Fire Resistant Cables/ Low Voltage Cable Standard for ISO 9001 / CCC Certificate

XLPE Insulation Fire Resistant Cables/ Low Voltage Cable Standard for ISO 9001 / CCC Certificate



1. Fire Resistant Cable Quick Details
Place of Origin: Henan, China (Mainland)
Brand Name: ZHENGLAN
Type: Low Voltage
Conductor:
1.5mm2 - 2.5mm2 : Class 1 solid conductor according to BS EN 60228
4mm2 : Class 2 stranded conductor according to BS EN 60228
Insulation Material: XLPE
Jacket: PVC or Low smoke halogen free polyolefin jacket
Sizes: 1.5~1000mm2
Number of cores: 1-5cores
Rated voltage: 0.6kv/1kv
Packaging Details: fully wooden drum, steel wooden drum, fully steel drum or customized

2. Fire Resistant Cable Application
Hard Skin Standard Fire Resistant Cables for use primarily in fire detection, fire alarm, voice alarm, and emergency lighting circuits. These cables are designed to continue to operate for a period of time in a fire situation. 'Standard' fire resistance is recommended for general use.

3. Fire Resistant Cable Standard
BS 5839-1:2013 Clause 26.2d, BS EN 61034-2, BS EN 60228 BS EN 50200:2015 (PH 30 - PH 60 - PH 120), BS 6387:2013 BS 5839-9, BS 5266-1, BS 8519, BS 7629-1, IEC 60331, BS 6387 (cat. C-W-Z), BS EN 50200, BS EN 50200 annex E, (class PH30 - PH60 - PH120), BS EN 60332-1-2, BS EN 60332-3-24 cat. C BS EN 60754-1, BS EN 60754-2


Why Choose Zhenglan Cable:

  • OEM/ODM services provided
  • Products comply with GB, IEC, BS, ASTM, DIN, VDE and JIS standards; Customer standard requirments Accepted
  • Certified to ISO 9001:2015, ISO 14001:2015 and OHSAS 18001:2007
  • Registered capital of $30 million and factory covers an area of 60,000㎡
  • Advanced test equipment and procedures, 100% inspection before factory
  • Enough stocks and the higest efficient shipping time guarranteed
  • Professional pre-sales and after-sales services provided

    Level Manufacturing British standard Applications
    Standard fire resistance BS7629-1,
    BS EN 50200 PH30, PH60 and PH120
    Fire resistant single core cables and multicore cables for BS5839-1 (most fire detection and fire alarm systems), BS5266 (emergency lighting and standard application circuits), and BS8519 (life safety and fire-fighting) category 1 control circuits. Where used under standard BS5839-1, standard fire-resisting cables should be considered to provide sufficient resistance to the effects of fire, with appropriate methods of support and jointing.
    Enhanced fire resistance BS7629-1, BS8434-2,
    BS EN 50200 PH30, PH60 and PH120
    Enhanced fire resistant cables are used in most public or complex buildings requiring emergency systems to remain operational for a minimum of two hours (PH120) in compliance with BS8434-2 and BS8519 category 1 & 2 control circuits. They are used for unsprinklered buildings with phased evacuation, unsprinklered buildings in excess of 30 metres in height, and where the designer, specifier or enforcing authority determines it is necessary on the basis of fire risk.
